Description
Standard Features
- Child or Adult ADA Compliant (when properly installed)
- Universal Bi-Level -Can be installed left high or right high with no additional parts
- Granite powder-coated apron and one- piece bottom wrapper
- Flexible, Low Flow, anti-microbial, anti-rotation, non-squirt bubbler
- 100 mesh inlet strainer
- Vandal resistant screws
- Individual hanging brackets provided
- Auto-stop allows cartridge and strainer service without shutting off water supply
Suggested Specifications
Model A172108F-UBL is a bi-level, self-contained, pressurized water cooler that shall deliver a minimum of 8.0 GPH (30.3 LPH) of water at 50°F (10°C) cooled from 80°F (26.7°C) inlet water and 90°F (32.2°C) ambient. Bubblers shall deliver a 0.3 GPM flow, have a flexible guard with an integrally designed non-squirt feature and operate on a water pressure range of 20-105 PSIG. Basins shall be constructed from 304 stainless steel and have an
integral drain. Cabinets shall be or stainless steel. Cooling system shall use R-134a refrigerant and be capillary tube Unit shall be activated from an anti-microbial push button in the front, using less than 5 pounds of force either galvanized steel with granite powder coat regulated. An adjustable thermostat with an off position shall regulate the refrigeration system. Unit shall be listed by Underwriters Laboratories for both the US and Canada and is compliant to the Air-Conditioning and Refrigeration Institute Standard 1010.
