Description
GENERAL INFORMATION
- Remote type, electric refrigerated, water chiller unit
- Chilling capacity of 31.9 gallons per hour of 50°F drinking water, based upon 80°F inlet water and 90°F ambient
- Compact, highly efficient water chiller units are designed for use where large quantity of chilled water is required
- May be located in a service area to serve up to three remote outlets (within 15 feet of chiller recommended)
- Also recommended for photo-processing, medical or experimental laboratories and a pre-cooler for beverage dispensing
COOLING SYSTEM
- Motor Compressor: Hermetically sealed, reciprocating type, 3/4 HP, 115VAC, 60Hz single phase. Sealed in lifetime oil supply. Power: Rated 13.2 Amps; 1015 Watts.
- Condenser: Water cooled. Cooling Unit: Combination tube-tank type. Tube portion is continuous coil of copper tubing. Tank is copper. Tank volume is 1.25 gallons.
- Refrigerant Control: Refrigerant HFC134a is controlled by accurately calibrated capillary tube for positively trouble-free operation.
- Temperature Control: Enclosed adjustable thermostat is factory preset. Requires no adjustment other than for altitude requirements.
Manufacturer Info
Elkay is the preferred source for products of superior value. Elkay is a supplier of high value commercial plumbing products that include drinking fountains, water coolers, faucets, and repair parts.
