Halsey Taylor HTICF Outdoor Drinking Fountain

Features and Benefits

• No more heavy, bulky coolers to clean and fill!
• Water is chilled through self-contained coils
• No electrical hook-up required
• Ice drawer slides out for easy filling
• Holds up to 30 lbs. of ice
• Satin finish stainless steel basin
• Single-stream, self-closing push-button projector made from chrome plated unleaded brass
• Rugged green polymer cabinet
• Blends in with the natural surrounding of golf courses and parks
• Optional Bubbler Cover Assembly
• Designed specifically for golf courses
• No lead containing components in the waterway construction

Cabinet

Insulated recycled green polymer cabinet is impact and rust resistant. Cabinet has heavy duty hinges and a heavy duty lockable hasp on cabinet door. (Lock not included) Bolt down kit included with cabinet.

Bubbler

Projector shall be chrome plated, unleaded brass, single-stream, self-closing, push-button operated with integral volume control for maintaining proper stream height. Also includes hood guard and anti-squirt feature.

Automatic Stream Height Regulator

Self-closing assembly is located inside unit to prevent tampering. Unit resists corrosion and liming. A constant stream height is automatically maintained under line pressures that vary from 20 to 105 psi.

Water Inlet

3/8” O.D. Tubing

Drain Outlet

1-1/4” tube outlet. Internal drain system directs water to rear of fountain. Drain system can be connected to a dedicated drain or French (gravel/rock) drain field.

Cooling

Water is chilled through self-contained coils so water source is never in contact with hands or ice. Cooling coil provides 4 cups of 50 degree F water every 8 minutes. (Tested at 80 degrees F incoming water and 90 degrees F outside temperature). No electrical hookup required. Ice drawer slides out for easy filling and holds up to 30 lbs of ice.

Suggested Specifications

Fountain shall have self-rimming stainless steel basin with satin finish. Projector to be pushbutton type with automatic stream control. To have removable drain strainer. The manufacturer shall certify the unit to meet the requirements of the Safe Drinking Water Act..
