Features and Benefits
- Ideal for applications prone to tampering such as prisons and educational facilities with curved profile offering a safe and unobtrusive design
- One-piece 14 GA stainless steel heavy-duty welded body includes basin with integral drain and side panels; no fasteners
- Gap-free panel joins to eliminate tamper access points
- Durable satin finish that resists stains and corrosion
- Vandal-resistant, self-closing pushbutton which requires tooling to prevent easy removal. Meets ADA activation force guidelines
- Vandal-resistant, heavy-duty one-piece drain formed into basin
- Vandal-resistant, heavy-duty, one-piece StreamSaver™ water-efficient bubbler.
- Rated for indoor and outdoor use (unless you get this unit with a Glass Filler or a Filter it will not be an outdoor rated fountain)
Cooling System
- Compressor: hermetically-sealed, reciprocating type, single phase. Sealed-in lifetime lubrication.
- Condenser: Fan cooled. Fan motor is permanently lubricated.
- Cooling Unit: Combination tube-tank type. Continuous copper tubing with stainless steel tank. Fully insulated with EPS foam which meets UL requirements for self-extinguishing material.
- Refrigerant Control: Refrigerant R134a is controlled by accurately calibrated capillary tube.
- Temperature Control: Enclosed adjustable thermostat is factory preset. Requires no adjustment other than for altitude requirements
Construction
- Frame: Galvanized structural steel chassis supports cooler housing
- Housing: Heavy-duty 14 gauge stainless steel cabinet with front access panel and integral basin
- Screened vents: Perforated vent screens prevent objects from being inserted into cooler
- Vandal-resistant StreamSaver™ Bubbler: One-piece, heavy-duty, solid construction. Reduces the flow of water by nearly 40% but maintains a steady, satisfying water stream. Keyed into position to prevent rotation. Over average market performance.
- Vandal-resistant Drain: Heavy-duty, one-piece construction
- Vandal-resistant Pushbutton: Heavy-duty, self-closing, easy to operate. Allows front access stream height adjustment.
- Note – Flow regulator provides constant stream from 20 to105 psi water pressure.
Manufacturer Info
Elkay is the preferred source for products of superior value. Elkay is a supplier of high value commercial plumbing products that include drinking fountains, water coolers, faucets, and repair parts.
