Features and Benefits
- Front vandal-resistant push button activation with less than 5 lbs of force
- One-piece, vandal-resistant, water-efficient bubbler which operates on 20-105 psi supply line pressure
- Shall include front access stream height adjustment
- Unit shall be constructed of 14 gauge stainless steel with integral basin
- Venting shall include protective screening
- WaterSentry® VII 1500-gallon capacity Filtration System, certified to NSF/ANSI 42 & 53 (Lead, Class 1 Particulate, Chlorine, Taste & Odor)
- Rated for indoor use
Cooling System
- Compressor: hermetically-sealed, reciprocating type, single phase. Sealed-in lifetime lubrication.
- Condenser: Fan cooled. Fan motor is permanently lubricated.
- Cooling Unit: Combination tube-tank type. Continuous copper tubing with stainless steel tank. Fully insulated with EPS foam which meets UL requirements for self-extinguishing material.
- Refrigerant Control: Refrigerant R134a is controlled by accurately calibrated capillary tube.
- Temperature Control: Enclosed adjustable thermostat is factory preset. Requires no adjustment other than for altitude requirements.
Construction
- Frame: Galvanized structural steel chassis supports cooler housing.
- Housing: Heavy-duty 14 gauge stainless steel cabinet with front access panel and integral basin.
- Screened vents: Perforated vent screens prevent objects from being inserted into cooler.
- Vandal-resistant StreamSaver™ Bubbler: One-piece, heavy-duty, solid construction. Reduces the flow of water by nearly 40% but maintains a steady, satisfying water stream. Over average market performance.
- Vandal-resistant Drain: Heavy-duty, one-piece construction.
- Vandal-resistant Pushbutton: Heavy-duty, self-closing, easy to operate. Allows front access stream height adjustment.
- Note – Flow regulator provides constant stream from 20 to 105 psi water pressure
Warranty:
5 year limited warranty on the unit’s refrigeration system. Electrical components and water system are warranted for 12 months from date of installation or 18 months from factory shipment, whichever date falls first.
Manufacturer Info
Elkay is the preferred source for products of superior value. Elkay is a supplier of high value commercial plumbing products that include drinking fountains, water coolers, faucets, and repair parts.
