Features and Benefits
- Cabinet: Stainless steel panels resists wear and corrosion. Durable satin finish helps hide water spots and fingerprints.
- Cooler Top: Non-corrosive stainless steel cooler top, number 300 series with satin finish resists stains and corrosion and is easy to maintain. Anti-splash ridge reduces splatter. Contoured to insure proper drainage.
- Water Conservation Bubbler: Designed to reduce water usage while still delivering a satisfying stream. Vandal-resistant bubbler is one-piece, chrome-plated, with integral hood guard design to prevent contamination from other users, airborne deposits and tampering.
- Push Bar Actuation Mechanism: Self-closing, vandal-resistant push-button does not require grasping or twisting.
- Automatic Stream Height Regulator: Self-closing assembly is located inside unit to prevent tampering. Unit resists corrosion and liming. A constant stream height is automatically maintained under line pressures that vary from 20 to 105 psi.
- Inlet Strainer: Easily cleaned in-line strainer screen traps particles of 140 microns or larger before they enter the waterway.
- Temperature Control: Positive sensing thermostat for controlling temperature of storage tank water. Factory set at 50° F Adjustable ± 5° F.
- Storage Tank: Non-pressurized stainless steel evaporator/storage tank for long life. Waterways are certified to NSF/ANSI 61, far exceeding the requirements of the Safe Drinking Water Act
- Refrigeration System: High-Efficiency, hermetically sealed, positive start compressor with lifetime lubrication and built-in overload protection, efficient capillary sizing, large capacity dryer-strainer, and self-lubricated fan cools copper/aluminum condenser. System uses R134A refrigerant. Protected by Halsey Taylor’s Limited 5 Year Warranty.
- Ventilation: Insure proper ventilation by maintaining 6” (152mm) minimum clearance from cabinet louvers to wall.
- Filtered: WaterSentry VII 1500 Gallon Filter
Suggested Specifications
Shall be GreenSpec® Listed, vandal resistant, self-contained electric refrigerated water cooler that shall deliver 8.0 GPH of 50º F water at 90º F ambient and 80º F inlet water. Shall have stainless steel basin with removable drain strainer. Bubbler shall be one-piece, lower-flow, vandal-resistant. Separate valve and automatic stream regulator shall be mounted within cabinet. Refrigeration system shall employ high-efficiency, positive start compressor using R134A, non-pressurized tank with optimized heat transfer and totally encapsulated insulation and be controlled by positive sensing thermostat. Unit shall comply with ANSI 117.1 and ADA for visual and motion disabilities. Unit shall be listed for indoor and outdoor service. The manufacturer shall certify the unit to meet the requirements of NSF/ANSI 61 and the Safe Water Drinking Act. The Halsey Taylor HVRGRN8 complies with ARI Standard 1010.
