Elkay EZWS-ERFP8-RF Retro-fit Soft Sides Bottle Filling Station

PRODUCT SPECIFICATION

In-wall EZWS-ERFP8-RF Retro-fit system will update existing refrigerated Bi-Level Soft Sides® installations with an integrated Bottle Filler system. Units shall be stainless steel construction with plastic ABS alcove. Sensor activation with an auto 20-second shut-off timer. Shall include GreenTicker™ displaying count of plastic bottles saved from waste. Bottle filler shall provide 1.1 gpm flow rate with laminar flow to minimize splashing. Shall include integrated silver ion anti-microbial protection in key areas. Bottle filler meets ADA guidelines for reach range; fountain meets ADA guidelines for wheelchair access. Unit shall be lead-free design which is certified to NSF/ANSI 61 and 372 and meets Federal and State low-lead requirements. Unit shall be certified to UL399 and CAN/CSA 22.2 No. 120.

STANDARD FEATURES

• No-touch, sensor-activated operation.
• Auto 20-second shut-off.
• Integrated Silver Ion Anti-microbial Protection in key areas
• Quick Fill Rate: 1.1 gpm
• Laminar Flow provides minimal splash
• Real Drain System eliminates standing water

FOUNTAINS / COOLING SYSTEM

One fountain, one mounting frame (for lower fountain installation)
and the cooling system are reused from the current existing
installation.

CONSTRUCTION

• Stainless steel bottle filler construction with ABS plastic alcove.
• Includes ventilating louvered grille with fountain.
• Furnished with open wall frame mounting box constructed of galvanized steel.
