Part #:
-
140165
-
Manufacturer:
-
Elkay / Halsey Taylor
-
Model #:
-
51300C
-
Packaging:
-
Boxed
-
Color:
-
White, Red
-
Dimensions:
-
H: 11-11/16”
-
Material / Construction:
-
Plastic
-
Weight:
-
1.70 lbs
-
Items Included:
-
Replacement Filter
1/4 Turn installation. Automatic inlet shut-off valve that closes when filter is removed. Hands never touch the actual filter media and, therefore, limit the potential for introduction of bacteria. Outer protective wrap. Spun Polypropylene prefilter mesh to prevent large, coarse sediment and particles from entering and clogging filter media. High-grade filter is made with activated carbon and patented ATS lead-removal media. Radial flow-thru design provides more surface area for untreated water while final filter mesh prevents loose carbon from entering water.
Design Features
- Size: 3-1/4” (82.6 mm) O.D. x 12-1/2” (317.5 mm) Length
- Water Inlet Connection: 3/8” (9.5 mm) O.D. Tube
- Water Outlet Connection: 1/ 4” (6.4 mm ) O.D. Tube
Recommended Use Conditions
- Filter Capacit y: 3000 gallon
- Maximum Flow Rate: 1.5 GPM
- Water Temperature: 40- 100°F
- Initial Pressure Drop: 2-5 PSI
- Maximum Line Pressure: 105 PSI
- Minimum Line Pressure: 20 PSI
